H100 Plus

Hemoglobin Analyzer (HPCL)

Specification

Methodology

High – Performance Liquid Chromatography (HPLC)

Test Modes

Variant Mode, Thalassemia Mode

Test Range

3% ~ 20%

Precision

CV < 1.5%

Test Speed

Variant Mode:58s         Thalassemia Mode:350s

Reagent Kit
  • Eluent A: 800mL, 1600mL
  • Eluent B: 800mL
  • Eluent C: 800mL
  • Eluent D: 800mL
  • Hemoglystic L: 5000mL
Sample Volume 5 uL
Hemoglobin Interferences
  • No interference from variants E,D,S,C,J,Hb Barts,HbH,HbCS
  • No interference from HbF up to 15%
Sample Rack Normal Sample Rack, Anemia Sample Rack, QC Rack, Calibrator Rack
Auto Sample Station 110 Positions+1 STAT Position
Display 10.1″ TFT True Color LCD Touch Screen
Storage 20,000 Sample Results
Connection Rs232, USB, LIS Compatible
Barcode Scanner Internal Barcode Scanner or Handheld Barcode Scanner
Printer Internal Thermal Printer and External Laser Printer
Temperature Storage Temperature 0~55, Operating temperature: 10~30
Humidity < 93%
Dimensions 772mm x 730mm x 729mm
Weight 62KG
