GH900 Plus

HbA1c Analyzer

Description

Lifotronic fully automated GH-900Plus HbA1c Analyzer supports fast HbA1c results output in 130 seconds without Hb variant interference. It provides the outstanding solution for reliable diabetic monitoring. No sample preparation and walk-away operation.

Gold Standard of Diabetes Diagnose

Glycosylated hemoglobin (HbA1c) is widely recognized as a Gold Standard to monitor diabetes, which can indicate the average plasma glucose concentration over 8~12 weeks.

HPLC Methodology

High-Pressure Liquid Chromatography (HPLC), to separate HbA1c directly with measuring the absorbance points continually to form chromatogram. Using normal distribution curve fitting auto-iterative algorithm to get precise HbA1c testing result, excluding interference of variant and unstable hemoglobin like LA1c. Standard Analysis Mode will report HbA1a, HbA1b, HbF, LA1c, HbA1c, HbAO peak areas and percentage. And the result also includes IFCC, NGSP and ADAG value for diverse client needs.

Specification

Methodology

High – Performance Liquid Chromatography (HPLC)

Test Modes

Variant Mode (A1c\E\D\S\C)

Test Range 3%-18%
Precision CV ≤ 1.5%
Test Speed Speed 130 Secs / Test
Sample Type Venous Blood, Finger Peripheral Blood, Lyophilized Whole Blood 10µL(whole blood), 400µl (Diluted blood)
Auto Sample Station 5 Positions/Rack
Photometer 415nm + 500nm Detector
Filter > 400T
Display 10.1″ TFT True Color LCD Touch Screen
Software Linux Software with Self – Diagnosis to Monitor and Detect System Errors
Reagent Kit Eluent A, Eluent B, Hemolysin L, Calibrator; QC Material
Information Input Scanner or Touch Keypad
Storage 4000 Sample Results
Connection USB, LAN, LIS Compatible
Printer Thermal Printer
Operation Temperature 10~30 °C (50~86 °F)
Humidity <80%
Power AC 100-240V 50/60HZ 120VA
Dimensions 450mm(L)*360mm(W)*540mm(H
Weight 32.8KG
